Power distribution units or PDUs are key components in data centers and telecommunication facilities. It is an electrical device used to distribute and manage power to multiple devices in a data center or telecommunications facility. It takes the main power supply and divides it into smaller branches, allowing safe and efficient distribution of power to devices.
The PDU can range from a basic unit that simply divides the power supply to more advanced models that provide monitoring, remote management, and other advanced features. These devices ensure the efficient distribution of power to the various servers, switches, and other equipment that make up a data center or telecommunications infrastructure.
| Rated Voltage | -48V |
| Insulation Resistance | ≥30MΩ |
| Insulating Intensity | Input-housing: AC1000V, 50Hz, 1 min; Output-housing: AC1000V, 50Hz, 1 min |
| Input Channels | 2 channels DC-48V, 63A |
| Output Channels | 8 channels (1-8 channels DC-48V, 20A) |
| Alarm System | Visual-aural alarm signal. Red LED and buzzer sound on channel failure. |
| Working Environment | Temp: 0°C~40°C; Humidity: ≤90%; Pressure: 70Kpa~106Kpa |
| Dimension | 485 mm * 135 mm * 85 mm (L*D*H) |
| Weight | 3.5Kg |
