📋 Basic Specifications
Application
Underground, Construction Equipment Welding Machine
Insulation Material
Rubber
⚡ AC1500V HV Flexible Cable
1.5kVac Flexible HV Cables For EV Use
(Reference Standard: DB44/T 2100-2018)
| Construction |
Features |
| 1. Conductor: Bare Copper |
1. Rated temperature: -40ºC ~ +(125ºC, 150ºC) |
| 2. Insulation: XLPE (Orange) |
2. Rated Voltage: AC 1500V |
| 3. Shielded: Tinned Copper |
3. Aging: 3000h (ISO6722 compliant) |
| 4. Sheath: XLPE (Orange) |
4. Flame Test: VW-1 (UL 2556) |
| Bending Radius: 4*OD / 6*OD |
Oil Resistance: IRM902, IRM903, Gasoline |
📊 Technical Parameters
| Product Series |
Size (mm²) |
Max. Resistance (mΩ/m@20ºC) |
Permissible Ampacity (A) |
Over Diameter (mm) |
| EVR-125 / EVR-150 | 2.5 | 7.60 | 30 | 3.50 |
| EVR-125 / EVR-150 | 4 | 4.71 | 40 | 4.50 |
| EVR-125 / EVR-150 | 6 | 3.14 | 52 | 5.00 |
| EVR-125 / EVR-150 | 10 | 1.82 | 70 | 6.40 |
| EVR-125 / EVR-150 | 16 | 1.16 | 95 | 8.00 |
| EVR-125 / EVR-150 | 25 | 0.743 | 130 | 10.00 |
| EVR-125 / EVR-150 | 35 | 0.527 | 160 | 11.00 |
| EVR-125 / EVR-150 | 50 | 0.368 | 210 | 13.00 |
| EVR-125 / EVR-150 | 70 | 0.259 | 260 | 15.00 |
| EVR-125 / EVR-150 | 95 | 0.196 | 320 | 17.30 |
| EVR-125 / EVR-150 | 120 | 0.153 | 370 | 19.50 |
❓ Frequently Asked Questions
How can I place an order?
You can contact us via inquiry with your order details or place an order online through our platform.
Does your company provide OEM & ODM services?
Yes, we can produce cables based on your specific samples or technical drawings to meet your requirements.
Do you test all goods before delivery?
Absolutely. We perform 100% testing on all products before they are dispatched to ensure quality stability.
Are you a professional cable and wire manufacturer?
Yes, we are an integrated industry and trade company specializing in high-quality special cable research and manufacturing.
Can you offer free samples?
According to your order quantity and requirements, we are pleased to provide samples for quality evaluation.
What are your terms of payment?
Our standard terms are T/T 30% as deposit and 70% before delivery. We also support EXW, FOB, CFR, and CIF terms.
