China TK360 Intelligent Battery Charger - Factory Direct Prices by STARWELL

Product Details

High efficiency(>85%).

GEL, standard, AGM, MOTO battery type can selectable

The 3-stage microprocessor controlled charging process provides the best possible application and enables efficient battery charging.

Charging voltage adapts to temperature, that can prevent over- or under-charging of battery.

Capable of recharging severely discharged or heavily sulfated battery. Reverse polarity protection, short circuit protection, over-charge protections, parks free contact.

LCD display: voltage, current, temperature etc

Ease of use. Clear charging status display.

Full microprocessor controlled.

Do not over-charge your battery even it is kept connecting in any mode

12V battery charger 12V 6A automatic smart 12 volt Motorcycle car battery charger

The TK360 intelligent battery charger has designed highly reliable and meet international safety and electromagnetic compatibility requirements.

A:Input Characteristics:

Input Voltage: 100-240Vac input AC voltage

Input Frequency: 50Hz or 60Hz and single phase.

B:Output Characteristics:

Constant Charging Voltage: 14.4V Float charge 13.8V

C:Charging Mode 12V battery charger 12V 6A automatic smart 12 volt Motorcycle car battery charger

3 Stages, CC, CV, Trickle

D:Safety Test for battery charger

Hi-pot Test:15KVac 5mA 3 Seconds between input and output test

Resistance:The battery charger insulation resistance shall be not less 30M ohms after application of 500Vdc/10mA for 3 Seconds

Drop test: Height: The battery charger conform to BS EN60068-2-32:1993 TEST ED: free fall appendix B

E:Protection for battery charger

Over Voltage Protection The battery charger will be auto recovered when faults remove

Over Current Protection Charger output current does not exceed the set maximum battery charging current.

Over Short Circuit Protection Battery charger output can be shorted without damage No odor, smoke, fire, plastic deformation, and excessive heal happen. The power shall be auto-recovery. (It will enter into normal condition when then the fault condition is removed)

Over reverse polarity Protection When the battery charger output line reversed after the charger will not work until the right user access only to start.

F:DC Connector Dimension:12V battery charger 12V 6A automatic smart 12 volt Motorcycle car battery charger

Optional output connector: 3-port Inline, 3-pin XLR, Alligator clip, 3-port House, Coaxial etc.

Special plug: 4-pin XLR, 2-port Inline, 3-pin House, Polarized, 3-port House for Panterra and Grio, Polarized C7 etc

Specification:

Name:	TK360 3-stage smart interlligent battery charger 12V 6A
Model:	TK-360
Input Voltage and current:	100-240V AC,50/60Hz
Output Voltage and current:	12V/6A
Port:	DC,AC
Battery Type:	DC12V lead-acid Battery
Output Power:	96W
Material:	ABS
Place of Origin:	China，Anhui
Protection:	-Polarity protection -Output short protection -Short circuit protection -Overvoltage protection -Overcurrent protection -Overheating protection -Reverse connection protection
Apply to:	car,motorcycle,vans
color:	Red
weight:	0.48KG
Dismension:	(L)155(W)75(H)63MM
Efficiency:	85%
Certification：	CE FCC ROHS PSE
